Simpson 260-8xi® & 260-8XPi® Analog VOM



260-8Xi has all of the advancements and circuit protection features for which the 260 Series is famous - PLUS MANY NEW ADVANTAGES:



It has even more features than you've come to expect from its predecessors. The yellow case color for enhanced visibility and user safety awareness is the trademark of the 260-8Xi. The durable ABS plastic case also provides high-impact resistance and increased drop protection in the toughest environments.




Instant Trend Information for Quick Positive "Yes/No" Checks
Zero RFI Emission
UL Listed
Audible Continuity Check


SPECIFICATIONS

DC Voltage
Ranges Accuracy Sensitivity
250mV, 1V, 2.5V, 10V ,25V, 50V, 250V, 500V, 1000V 2% of full scale 20k per volt

AC Voltage
Ranges Accuracy Sensitivity
2.5V, 10V, 25V, 50V, 250V, 500V, 1000V 3% of full scale 5k per volt

AC Current Up to 250 AC amperes with AC Amp-Clamp Adapter Accessory 00541.
Decibel 5 Ranges: -20 to +50dB Reference: 0dB= 1mW into 600

DC Current
Ranges Accuracy Voltage Drop (Nominal)
50A, 1mA, 10mA, l00mA, 500mA, 10A 1.5% full scale 50A 2.0% of full scale, all other 250mV on 50A, 1mA; 255mV on 10mA , 10A; 300mV on 100mA; 500mV on 500mA



Resettable Overload Circuit Protection Relay (260-8XPi Only)
Includes 1.5 V and 9 V Batteries and Probe Test Leads With Alligator Clips
Mirrored Scale for Parallax Reduction




Resistance
Ranges Accuracy Maximum Indication
Rx 1 Rx 100 Rx 10K 2.5 of arc on Rx1 2.0 of arc on other 0-2K 0-200K 0-20M


FUSE: F1 1A, 250V, type 3AG, quick acting Littelfuse® Type 312001; F2 2A, 600V Littelfuse® Type BLS or 2A 600V, Bussman® Type BBS.
BATTERIES: 1.5V AA, 9V (Neda No. 13F, 1604A)
SIZE: 5 1/4" x 7" x 3 1/8" (13.34 x 17.78 x 7.94 cm)
WEIGHT:2 1/4 lbs. (1.02 Kg)
RATED CIRCUIT-TO-GROUND VOLTAGE: 1000V AC/DC Max Specifications subject to change without notice.


VOM Catalog Number Accessories Catalog Number Accessories Catalog Number Accessories Catalog Number Accessories Catalog Number
260-8Xi, Yellow 260-8XPi, Protected, Yellow 12395 12396 Universal Kit, Deluxe 19-Piece Universal Kit, 14-Piece Probe Leads w/Screw-on Alligator Clip) 00545 05577 00818 00043 Case,Yellow Padded Polyester Case, Black Padded Polyester Roll-Top Case Case, Hard Leatherette Front Load Case, Molded Plastic 00818 05577 00125 Probe Set, Replaceable Tip, Banana Lead Set, Alligator, Banana Clip Set, Alligator, Screw-On 150-2 Amp Clamp Adapter, AC 151-2 Power Line Splitter (for 150-2) 07538 07500 00425 00541 00544 Case, Yellow Padded Polyester Case, Black Padded Polyester Case, Hard Leatherette Front Load Case, Molded Plastic 00832 00834 00805 45028
